| Size:1/2”-24” |
Design |
ASME b16.34/BS 5352 /API / 600 BS 1873/API 602 |
| Class:150-2500 |
Face to Face |
ASME B10 |
| CS / SS / ALLOY / MONEL / Hastalloy Body |
End to End |
SW / BW / Flanged |
| Hand lever / Gear Box / Pneumatic / Electrical Actuator |
End Flange |
ASME B16.5/DIN /BS/IS |
| Cycling2000 /10000 / 20000 |
SW / BW End |
ASME B16.11 / B16.25 |
| Service:Chlorine Hot Oil High Temperature |
Test |
API 598 / BS6755 |
| Speciallity:bellow Failure Indicator On request |
Bellow |
Inconel / SS / Hast Alloy |
| Bellow construction Single Ply / MultiplePly |
Seat |
Metal to Metal/metal to Soft seat |
