Specialty Features | Specification | |
---|---|---|
Size:3/8”-10” (10mm-250mm) | Design | ASME B16.34/API 526/520 |
Class:150-2500 | Face to End | API 526 |
CS / CI / SS / Alloy s/ Monel / Hastalloys / MOC | End to End | SW / SCR Type / Flange End |
Open / Closed / Lever | End Flange | ASME B16.5 / DIN / BS / IS / JIS |
Spring / Dead weight | SW End | ASME B16.11 |
Semi Nozzle / Full nozzle | Test | API 527 |
Speciality :Bellow Sealed Cryogenic And High Temp | set pressure Test | As per as client Specification |
Metal to Metal and Metal to Soft Seat | Special | NACE MR-01-75 |
