| Size: 1/2”-16”(15mm-400mm) |
Design |
ASME B16.34 |
| Class: 150-2500 |
Face to Face |
ISA 75.03 (Upto 600) & ISA 75.16 (900Above) |
| Two / Three Way CS / SS / Siloys / Monel / Hastalloys / Material construction |
End &End |
Flanged / Screwed / SW / BW |
| Direct and Reverse Actuater Diapharm Type Spring Return |
End Flange |
ASME b16.5 / DIN / BS / IS |
| Electric Actuater with intergral Starter Input4to 20mA |
BW End |
ASME B16.25 |
| Smart / Electropneunematic / Pneunematic |
Test |
FCI-70-2(ANSI B16.104) |
| I/P Converter |
|
|
| Position Transmitter |
Special |
NACE MR-01-75 |
| Actuation ::Pnenematic / Electrical Actuator |
|
| Speciality |
cage With Pressure Balancing arrangment |
|
